Coated Aluminum Coil

coated aluminum coils

The coated aluminum coil is ideal for producing aluminium composite materials. Mintai aluminium coil is coated with high quality fluororesin paint which offers good weather resistance.Mintai Coated Aluminum Coil is the Leading Coated Aluminum coil exporter in China.

Where can Mintai coated aluminum coil be used?
- To produce aluminium composite panel or aluminum veneers.
- Used in exterior applications for decoration and protection of exterior wall, canopy, roof and pillar, etc.
- Mintai coated aluminum coil is also ideal for interior decoration for wall, ceiling, bathroom and kitchen, etc.
- Used in advertising boards or shop front decoration.

Packing
- Inner Core: Paper Tube
- Outer: Paperboard
- Wooden Pallet

As a one of the foremost coated aluminum coil manufacturers and suppliers in China, all coated coils are painted by Mintai own coating production line. Mintai can produce different aluminium coil coming with different types of coating, including, PVDF coated, polyester coated, brushed and chromated cleaning coils. Given below are the detailed specifications for your reference.

PVDF coated aluminum coil

Aluminum Alloy AA1100; AA3003; AA5005
Coil thickness 0.25mm,0.30mm,0.40mm,0.50mm
Coil width 1240mm, 1270mm, 1520mm, 1550mm, 1575mm
Coating thickness Over 25 micro
Diameter 405mm, 505mm
Coil weight 2.5 to 3.0 tons per coil
Color White series, metallic series, Dark series, Gold series( accept color customs)

Polyester coated aluminum coil

Aluminum Alloy AA1100; AA3003; AA5005
Coil thickness 0.18mm,0.21mm,0.25mm,0.30mm,0.40mm,0.45mm,0.50mm
Coil width 1240mm, 1270mm, 1520mm,
Coating thickness Over 16 micro
Diameter 405mm, 505mm
Coil weight 2.5 to 3.0 tons per coil
Color White series, metallic series, Dark series, Gold series( accept color customs)

Brush finish aluminum coil

Aluminum Alloy AA1100; AA3003
Coil thickness 0.15mm, 0.21mm, 0.30mm, 0.40mm, 0.50mm
Coil width 1240mm, 1270mm, 1520mm,
Diameter 405mm, 505mm
Coil weight 2.5 to 3.0 tons per coil
Color Silver & gold

Clean chromated aluminum coil

Aluminum Alloy AA1100; AA3003
Coil thickness 0.15mm, 0.21mm, 0.25mm, 0.30mm, 0.40mm, 0.45mm, 0.50mm
Coil width 1240mm, 1270mm, 1520mm,
Diameter 405mm, 505mm
Coil weight 2.5 to 3.0 tons per coil

In addition to various coated aluminum coil, Mintai can also provide aluminum composite panel, aluminum ceiling, and sandstone tile, etc. All Mintail products are widely used in the United States, Australia, Russia, Iran, and Japan, to name just a few.
If you are searching for coated aluminum coil or related products, please feel free to contact us. We are ready to serve you.

Where can Mintai aluminum plastic composite panel be used?


-Gas piping, cables, building materials, etc (this product fills a gap in the domestic construction materials field, with performance indexes superior to panels manufactured overseas)
- Curtain wall decoration for buildings where security is important, such as airports, hospitals and research centers
- Curtain wallboards for outside walls of normal buildings
- Renovations of old buildings and movable houses
- Reformation and decoration for indoor walls, ceilings, bathrooms, kitchens and balconies
- Facades
- Billboards, exhibition desks and notice boards
- Wallboards and ceilings for tunnels
-Materials for industrial application, car and ship bodies

Packing:
-About 200 pcs per pallet
-Wooden pallet or wooden case/box
-MOQ:200 pcs

SPECIFICATION:

Standard size

1220mm*2440mm*3mm/4mm

Width

As customer requirement

Length

As customer requirement

Panel thickness

3mm to 6mm

Aluminum thickness

0.05mm-0.5mm

Weight

5kg/sqm,based on 4*0.4mm

Color Match
1. For custom' color requests, we can deal as following:
A. Supply a physical sample of custom color. A color sample on metal is preferred. If other, it is also acceptable.
 But the color matching rate may be not good as color on metal.
B. New color sample is usually offered by our paint supplier in 5-7 days, special color should be in 7-10 days.
C. Upon receipt of color sample, please approve in writing as soon as possible. Once you approved, we will
 arrange purchasing and production.
Note: Color difference maybe occurred in different production batch, so it is suggested all panels are placed in
 one order for same project. And keep same direction as arrow on protective film when installing to avoid
any color difference by vision.
2.For general colors, please refer to our color chart

Characteristics:

1) Excellent fireproof property
2) Super peeling strength
3) Perfect cold resistance performance
4) Excellent surface flatness and smoothness
5) Superior weather, corrosion, pollutant resistance
6) Even coating, various colors
7) Superior impact resistance
8) Lightweight and easy to process
9) Easy to maintain
